GRUNDFOS SP 3A-33 2.2 KW 380V

899.00  excl. VAT

In stock

  • Ø Outside diameter 4 inch
  • Pump outlet Rp 1″ 1/4
  • Flow (Q) 3 m³/h
  • Head (H) 147 m
  • Motor MS402
  • Power 2.2 kW

Frequently Bought Together

This borehole pump is engineered for pumping clear water. It is possible to install it either vertically or horizontally. The main component of this pump is stainless steel, EN 1.4301 (AISI 304) which is highly corrosion-proof. This instrument is ratified for drinking water usage. The motor features a lip seal, a special shield, which protects it from sand, bearings with liquefied lubrication and a compensation membrane. A 2.2 kW motor offers perfect stability and effectiveness. It is able to work in temperatures up to 40 °C. There is no sensor for temp. in the motor, so if controlling it is necessary, fitting a Pt1000 detector is possible. Direct-on-line starting (DOL) is the main characteristic of this motor.

Ø Outside diameter 4 inch
Pump outlet Rp 1″ 1/4
Flow (Q) 3 m³/h
Head (H) 147 m
Motor MS402
Power 2.2 kW
Frequency 50 Hz
Voltage 3 x 380-400-415 V
Current 5,50-5,50-5,70 A
Net weight 20.7 kg
Gross weight 22.5 kg

Optional

Neoprene Cable 4G2.5 mm² – as standard.

DRINCABLE 4G2.5 mm² – cable certified for potable water – on request.

Grundfos SP 3A Series Curves

Grundfos SP 3A Series
